High Tensile Steel Strapping for Wool Blade

High Tensile Steel Strapping for Wool Blade

We specialized in the prduction of high tensile steel strappings with tensile strength over 930Mpa and heat-treating teel strips(hardened and temered steel strip as well as cold rolled annealed steel strip). The strappings manufactured from special cold rolled steel coil, an deburred, heat treated, paintd and waxed in a continued line by automatic machining controlling to botain high strength and excellent shock resistance hich are for heavy duty products applications.

  • Product Description
High Tensile Steel Strapping for Wool Blade

Steel strapping with high strength specifications

Physical Properties



Thickness x Width

thickness(mm) width(mm)

0.40

16
0.50 16,19
0.60 16,19
0.70 19
0.80 19,25.4,31.75,32
0.90 19,25.4,31.75,32,40
1.0 19,25.4,31.75,32,40
1.2 31.75,32,40

thickness toleance

 0.40~0.60+/-0.002mm

      0.70~1.20+/-0.003mm

width tolearance

16-40mm+/-0.1mm



Finish

Blue tempered + Waxed

Painted + Waxed, such as black, brown, green, etc

Zinc coated + waxed





Coil Dimension

Coil I.D: 200mm, 300mm, 406mm

Coil O.D (max): 1000mm



Coil winding    Coil face  Coil weight
Ribbon wound

16mm,19mm,

25.4mm,31.75mm,

32mm,40mm

45-50kgs
Oscillated wound 63.5mm 50kgs
Jumbo wound 190mm 200-400kgs







Packing:

Each bundle is packed with water proof paper and put onto

wooden pallet or iron pallet



Application

steel industry(steel coil, steel sheet, steel tube, steel bar)

plywood packing, timeber packing, brick packing

cotton, wool, jute, glass, oil tank

other heavy duty products etc



Note

sizes, breaking load min, finish, coiling type, coil I.D, coil O.D, can be made accord. to customers`s requirement
