Blue Black Green Brown Steel Strapping

Blue Black Green Brown Steel Strapping

High tensile steel strappings manufactured from special cold rolled steel coil, are debureed, heat treated, pained and waxed in continued line by automatic machining controlling to obtain high strength and excellent shock resstance which ae for heavy dut products applications.High tensile steel strappings are manufactured from a special cold rolled steel and are heat - treated to get high tensil strength above 930Mpa and the elongation over 6%.

  • Product Description







Blue Black Green Brown Steel Strapping

Steel strapping with high strength specifications

Physical Properties



Thickness x Width

thickness(mm) width(mm)

0.40

16
0.50 16,19
0.60 16,19
0.70 19
0.80 19,25.4,31.75,32
0.90 19,25.4,31.75,32,40
1.0 19,25.4,31.75,32,40
1.2 31.75,32,40

thickness toleance

 0.40~0.60+/-0.002mm

      0.70~1.20+/-0.003mm

width tolearance

16-40mm+/-0.1mm



Finish

Blue tempered + Waxed

Painted + Waxed, such as black, brown, green, etc

Zinc coated + waxed





Coil Dimension

Coil I.D: 200mm, 300mm, 406mm

Coil O.D (max): 1000mm



Coil winding    Coil face  Coil weight
Ribbon wound

16mm,19mm,

25.4mm,31.75mm,

32mm,40mm

45-50kgs
Oscillated wound 63.5mm 50kgs
Jumbo wound 190mm 200-400kgs







Packing:

Each bundle is packed with water proof paper and put onto

wooden pallet or iron pallet



Application

steel industry(steel coil, steel sheet, steel tube, steel bar)

plywood packing, timeber packing, brick packing

cotton, wool, jute, glass, oil tank

other heavy duty products etc



Note

sizes, breaking load min, finish, coiling type, coil I.D, coil O.D, can be made accord. to customers`s requirement.
